Be honest. Do you check floor surfaces completely and accurately every time? This was almost impossible anyway with the previous point-by-point methods. Or if at all possible, it would require a lot of time and personnel. This is now visibly easier to do because the new GSL 2 Professional enables you to check floors completely in no time. It is ideal for everyone who works with floor surfaces – for composite floor layers, tilers, parquet layers, drywallers and surveyors.

The principle is ingeniously simple – and simply ingenious. The floor surface laser projects two lines onto the floor. If the surface is flat, the lines will be exactly on top of each other. The user will see them as only one line. Where the lines are apart, the floor is not flat.

Fast and Easy

No need to bend down, re-measure, or get someone to assist you: even large surfaces can be comfortably checked by only one person with a remote control!

Accurate

The GSL 2 enables to see the high and low spots at a glance with accuracy and reliability

Complete coverage

Unlike conventional spot checking methods the GSL 2 checks floor surface in a radius of up to 60 ft in just a few minutes. It saves time and increases the accuracy

How to Operate

This revolutionary new laser by Bosch introduces not only a new tool to the world, but also a tool that is simple and straight-forward for every user. To use the GSL 2 laser, simply place it at your desired benchmark on the floor that you would like the rest of the floor to match. Then, turn on the laser via the sliding switch located on the side of the tool. After that, adjust the height of the laser until the two lines come together as one on the floor. The height adjustment range is 1-3/16-inches. Then, initiate the scan of the floor surface with your RC 2 remote control (make sure to stand facing the laser when operating with the RC 2 remote). Observe the lines on the floor and watch as the lines separate along the floor surface or at points. At those separated areas, bumps, or recesses, read the height of deviation with a target plane and mark for re-work.

User Features

The Bosch GSL 2 surface laser incorporates several special features to increase both the performance and user ease of the tool. On the exterior of the tool are the carrying handle, on/off switch, and height adjustor. In addition, there is the LED battery indicator light conveniently located on top of the laser so you never have to move the tool to see the status of your battery light. On the interior there is a signal receiving area, motorized rotary base, and laser exit. This laser is also self-leveling to warrant accurate delivery of results. The self-leveling range is plus-or-minus 4-degrees.

Battery Compatibility

This GSL 2 surface laser has been ingress protection 54 (IP 54) jobsite tested. It can be used with the four AA 1.5-volt alkaline batteries that are included. In addition, it can be used with a Bosch 10.8-volt lithium-ion battery pack. The typical operating time is 15 hours, and it can be used in temperatures ranging from 14-degrees to 122-degrees Fahrenheit (negative 10-degrees to 50-degrees Celsius).

Laser Features

This Bosch laser class is 3R with a self-leveling time and range of around 5 seconds, plus-or-minus 4-degrees. When the laser becomes out of level, the warning pattern is the line flashing on for 1/2-second and then off for 1/2-second to easily alert the user. The measured accuracy is approximately within 1/8-inch at a distance of 30-feet. The regular line visibility is 30-feet and 65-feet with a target plane. The working range is up to 65-feet when being operated with the remote control. In addition, the receiving area size horizontal is 120-degrees at 16-feet and 90-degrees at 33-feet. The vertical opening is always 90-degrees. The rotation speed can vary at tje slow speed of 0.3 RPM to the quick speed of 1 RPM.

RC 2 Remote Control

The GSL 2 surface laser comes with the RC 2 remote control. This remote control feature allows the user to not be restricted to the spot of the tool with a working range up to 65-feet. It can be used with 3 AAA 1.5-volt alkaline batteries and operate in a temperature of 14-degrees to 122-degrees Fahrenheit (negative 10-degrees to 50-degrees Celsius). It has an ingress protection of 5X that is dust protected. The remote control has a rotation-per-minute speed ranging from 1- to 3-minutes.

Bosch GSL 2 Professional Surface Laser Features:

• Speed – check large areas quickly and efficiently
• Precision – surface laser allows user to measure irregularities height / depth to millimetre accuracy
• Complete coverage – checks surfaces completely oppose to conventional spot checking methods
• Visibility – laser lines clearly visible on surface up to 10 m and 20 m with target plate
• Robust – comes with IP54 dust and splash protection
• Innovation – new innovative method of checking surface evenness aimed at saving the user time and money
• Carry handle – allows for easy transportation
• Height adjustment – manually adjust height of unit
• Manual rotary base – rotate base to face required direction
• Uses standard Bosch 10.8v li-ion batteries (not supplied) or 4 x AA batteries
• Battery status LED shows battery life

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]

Technical data: Bosch GSL 2 Professional Surface Laser

Accuracy	Up to ±1/8-in @ 30-ft (Horizontal & Vertical)
Battery	12V Max Lithium-ion Battery
Battery	4 AA 1.5V Batteries
Dimensions	8.3″ x 7.7″ x 8.1″
Laser Diode	630 – 670 nm Class 3R
Leveling Type	Self-Leveling, Up to 4°
Operating Temperature	14°F / -10°C ~122°F / 50°C
Range	Up to 30ft without Target Plate, Up to 60ft with Target Plate
Weight (lbs.)	3.3 lbs

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• GSL 2 Professional
• 10.8 V Li-Ion battery
• Charger
• RC 2 remote control
• 3 x AAA 1.5 V (for the remote control)
• Target
• Laser viewing glasses
• L-BOXX carrying case

[/vc_tab][vc_tab title=”Downloads” tab_id=”downloads”]

Brochure

• Bosch GSL 2 Surface Laser Leaflet

User Manual

• Bosch GSL 2 Surface Laser User Manual

[/vc_tab] [/vc_tabs]

[vc_separator width=”1/1″ el_position=”first last”] [vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

Every aspect of the Bosch GOL 32D demonstrates how series Bosch are with getting their survey tools designed and built to meet the users requirements. The Bosch Site Level GOL 32 D is not just another level. The Site proof casing surrounds the very high quality 32x magnification optics that offers clear images of the levelling staff over long and short distances. The housing on the Bosch 32D Automatic Level is solid with an easy 360 degree rotation plate with clear precise position marks. The base plate of the site level sits firmly on the Bosch Site tripod included with this kit. The site tripod is strong enough to be loaded used time and time again in all site environments offering a very stable platform for the Site Level. The Bosch 5 Meter levelling staff complements this excellent value package – The Bosch GOL 32 D Optical Site Level.

Bosch GOL 32D Professional Features:

• Designed for outdoor use due to sturdy metal housing with dust and splash protection (IP54)
• Robust design with built-in target collimator and integrated circular vial
• Compensator lock for safe transport
• Target collimator for rough alignment
• Penta prism makes it easy to read the circular vial
• Large focusing knob for easy alignment
• Fast aperture for excellent staff reading
• High precision (1.6 mm/30 m) over long distances
• Endless angle setting using knobs on both sides with friction-braked rotation
• Erect image

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]

Technical data: Bosch GOL 32D Professional Level

Model	Bosch GOL 32D Professional
Unit of measure	360 degrees
Magnification	32x
Levelling accuracy	1 mm at 30 m
Working range	up to 120 m
Dust and splash protection	IP 54
Tripod thread	5/8″
Operating temperature	-10 – 50 °C
Storage temperature	-20 – 70 °C
Length	215 mm
Width	135 mm
Height	145 mm
Weight, approx.	1.7 kg

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab] [/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”][vc_tab title=”Description” tab_id=”description”]

This laser is multipurpose, making it ideal for tradesmen who work a variety of jobs involving squaring, plumbing, and leveling where a multifunction tool is required. If you are an electrician, plumber, kitchen installer, framer, drywaller, or general contractor, this is the laser for you. It can be used for a variety of applications, including transferring points to the ceiling or lighting installations using plumb points or square a room for partition or walls.

Multi-Use Combination Laser

The GCL 25 laser by Bosch has five different points that offer solutions across the most common applications. The applications it is built to examine include: horizontal leveling, vertical leveling, squaring, plumb transfer, and layout. The best part about this tool’s versatility across common applications is that you no longer have to pack two lasers to the jobsite or off-site project, because you have the combined power of two-in-one. This laser saves you time, money, and space with the simple switch of a button.

User Features

The Bosch GCL 25 laser incorporates several special features to increase both the performance and user ease of the tool. Located conveniently on the exterior of the tool is the on/off sliding button, LED battery status, and line/point selection keypad. The on/off sliding button features a pendulum lock function and is easy to reach. It has three different levels that are: the laser is on and in self-leveling mode, the laser is on but self-leveling is off, or the laser is off. The LED battery status is located on top of the tool for added user convenience so that you don’t have to go looking for the current battery status. In addition, this laser is ergonomically designed for a comfortable and solid grip. On the interior of the tool are the tripod thread, self-leveler, and accuracy feature. The tripod thread measures at 1/4-inch and 5/8-inch. The self-leveling feature measures within 4-degrees. The accuracy feature allows for accuracy within 1/8-inch on horizontal points, 9/16-inches on vertical points, and 1/8-inch on cross-line. The points are also visible for up to 100-feet, and the lines respectively up to 33-feet. This laser is also protected against dust and splash water with ingress protection 54 (IP 54).

Keyboard Operation

The keypad is controlled by how many times you press the keypad. When the pendulum is unlocked and the laser has self-leveling on, the different levels are: default mode where you will have cross-lines (turning it on), 5 point mode (first press of keypad), horizontal line only (second press of keypad), vertical line only (third press of keypad), and return to default mode (fourth press of keypad). When the pendulum is locked (slope mode) and the laser has self-leveling off, the different levels are: cross-line mode (default mode), horizontal line (first press of keypad), vertical line (second press of keypad), or back to default (third press of keypad). Please note that when you are in slope mode, the points are used to plumb and align partitions based on their 90-degree angle to each other. The important precondition for these applications is to have the points leveled. Using the points in non-self-leveling mode may lead to an error. To avoid this error, only the lines are activated for the leveling applications when the laser is in slop mode.

Industry Leader

This GCL 25 laser is outstanding in comparison to the GPL2, GPL3, or CPL5. To begin, it out numbers the other models by featuring a cross-line in addition to five laser dots. It also has a plumb range of 15-feet, a horizontal point range of 100-feet, and a lines range of 30-feet. The accuracy is unique to the GCL25 of within 1/8-inch at 30-feet. The self-leveling within 4-degrees is also only a feature you will get with this laser. It is also not limited to basic applications, covering plumbing, horizontal leveling, squaring, and versatile alignment. It also has the ability to set right angles.

Bosch GCL 25 Five-Point Laser with Cross-Line Features:

• Extremely versatile: cross line laser and five-point laser in one covers all interior alignment applications
• Horizontal and vertical levelling, square, layout and plumb transfer
• Easy to operate using intuitive user interface
• Compact and ergonomic design for maximum grip and end user comfort
• Robust instrument for jobsite use with IP54 dust and splash protection
• 10 m cross line range, 30 m point projection
• Touchpad for line/point selection
• LED light showing battery status
• Tripod compatible 1/4″ and 5/8″ tripod thread
• On/off sliding button with pendulum lock function

Bosch GCL 25 Professional Applications

• Plumbing: Plumb point for pipe installation
• Dry walling: Setting up partition walls
• Electrician: Plumb points for spot lighting
• Kitchen installer: Levelling cupboards

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]

Technical data: Bosch GSL 2 Professional Surface Laser

Specifications	GCL 25 Professional
Working range of laser points	30 m for forward, right and left points   10 m for upward plumb point   5 m for downward plumb point
Working range of laser lines	10 m
Leveling accuracy	0.3 mm / m, plumb points 0.5 mm / m
Self-leveling range	± 4 °
Typical leveling time	<4 s
Dust and splash protection	IP54
Energy supply / Operating time	4 x AA LR06 1.5 V / approx. 15 h   (2 lines + 5 points)
Dimensions (L x H x W)	155 x 118 x 56 mm
Weight including batteries	600 g

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• GCL 25 Professional
• L-Boxx inlay
• 4 x AA Batteries

[/vc_tab][vc_tab title=”Downloads” tab_id=”downloads”]

Brochure

• Bosch GCL 25 Professional Leaflet

User Manual

• Bosch GSL 2 Surface Laser User Manual

[/vc_tab][/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

Be honest. Do you check floor surfaces completely and accurately every time? This was almost impossible anyway with the previous point-by-point methods. Or if at all possible, it would require a lot of time and personnel. This is now visibly easier to do because the new GSL 2 Professional enables you to check floors completely in no time. It is ideal for everyone who works with floor surfaces – for composite floor layers, tilers, parquet layers, drywallers and surveyors.

The principle is ingeniously simple – and simply ingenious. The floor surface laser projects two lines onto the floor. If the surface is flat, the lines will be exactly on top of each other. The user will see them as only one line. Where the lines are apart, the floor is not flat.

Fast and Easy

No need to bend down, re-measure, or get someone to assist you: even large surfaces can be comfortably checked by only one person with a remote control!

Accurate

The GSL 2 enables to see the high and low spots at a glance with accuracy and reliability

Complete coverage

Unlike conventional spot checking methods the GSL 2 checks floor surface in a radius of up to 60 ft in just a few minutes. It saves time and increases the accuracy

Bosch GSL 2 Professional Surface Laser Features:

• Speed – check large areas quickly and efficiently
• Precision – surface laser allows user to measure irregularities height / depth to millimetre accuracy
• Complete coverage – checks surfaces completely oppose to conventional spot checking methods
• Visibility – laser lines clearly visible on surface up to 10 m and 20 m with target plate
• Robust – comes with IP54 dust and splash protection
• Innovation – new innovative method of checking surface evenness aimed at saving the user time and money
• Carry handle – allows for easy transportation
• Height adjustment – manually adjust height of unit
• Manual rotary base – rotate base to face required direction
• Uses standard Bosch 10.8v li-ion batteries (not supplied) or 4 x AA batteries
• Battery status LED shows battery life

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]

Technical data: Bosch GSL 2 Professional Surface Laser

Accuracy	Up to ±1/8-in @ 30-ft (Horizontal & Vertical)
Battery	12V Max Lithium-ion Battery
Battery	4 AA 1.5V Batteries
Dimensions	8.3″ x 7.7″ x 8.1″
Laser Diode	630 – 670 nm Class 3R
Leveling Type	Self-Leveling, Up to 4°
Operating Temperature	14°F / -10°C ~122°F / 50°C
Range	Up to 30ft without Target Plate, Up to 60ft with Target Plate
Weight (lbs.)	3.3 lbs

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• GSL 2 Professional (without motor)
• 4 x AA 1.5 V batteries
• Target
• Laser viewing glasses
• L-BOXX carrying case

[/vc_tab][vc_tab title=”Downloads” tab_id=”downloads”]

Brochure

• Bosch GSL 2 Surface Laser Leaflet

User Manual

• Bosch GSL 2 Surface Laser User Manual
