Key Features of Leica UTILIFINDER+ Buried Utility Locator

Cable and other utilities could run underneath any part of a domestic property. Before excavating for a path, landscaping a garden or installing a fence, it is critical to search for buried utilities.

Detect live cables with Auto mode
Use Auto mode to search for loaded power cables and other utilities with a detectable signal. A signal is produced by a current passing through the utility and is detectable by the Leica UTILIFINDER+ in Auto mode. This mode also features a proximity alarm to warn of shallow buried utilities.

Induce a signal with UTILIGEN
Some cables may not carry a detectable current but still pose a serious threat if damaged.

To detect these dormant cables, plug the UTILIGEN into a household socket and apply a detectable signal. Use the UTILIFINDER+ to detect this signal and obtain a depth reading with a simple press of a button.

Where possible, the signal will also connect onto other utilities such as telecom cables and water pipes, which the UTILIFINDER+ will also detect.

Search for drains with UTILIDRAIN
On occasions you may want to trace the route of drains or waste water pipes or find a blocked pipe. Insert UTILIDRAIN into the drain and pass along using drain rods or reels.

The UTILIDRAIN will emit a traceable signal which can be detected by the Leica UTILIFINDER+. Obtain a depth reading with a simple press of a button.

Single trigger
Positioned directly under the handle for simplicity of use, press and hold the trigger to activate UTILIFNDER+, release to switch off. The use of a trigger extends battery life and removes the On/Off button, which can leave the instrument turned on, draining the battery power.

Large clear mono display
The large clear display provides easy reading of the Signal Strength Indicator (SSI).
This display provides easy reading and information to the utilities position. Numeric and graphical signal strength indicators provide a confident locate.

Audible confirmation sound
Supporting the display, an audible sound confirms the presence of the detected utility.

Obtain a depth reading
Knowing the depth of the utility provides additional information and can contribute to safer work prac-tices. Depth estimation is obtainable when using the UTILIGEN or UTILIDRAIN accessories and can be provided down to a depth of 3 metres.

Ruggedness
The UTILIFINDER+ has been designed to be IP54, protecting against wet and damp conditions.

No calibration required
The UTILIFINDER+ will not require calibration, removing continued calibration costs.

The complexity of underground utility networks are continually increasing. So obtaining precise information on the location of buried utilities has never been more important. The protection of buried assets during excavation work demands accurate mapping and surveying of existing utilities.

The Leica ULTRA provides our most advanced precision utility tracing system. Intelligent signal processing has been integrated with unique flexible operating modes, to help save you time and increased confidence in your results. Selectable antenna and customised frequencies optimises your instrument for site specific applications, supported by our AIM system which monitors signal interference levels, recommending which mode to use for the best results.

Unlock the power

• Configure the Leica ULTRA for site specific applications. Custom build your receiver and transmitter.
• Choose from over 100 preselected frequencies, or customise your own frequency for highly specialised applications.
• Automatically capture the instruments location data to ensure adherence to best practice. The data logging feature allows the user to record external GPS coordinates and download with the datafile as a KML or CSV format. Upload into GIS systems or Google Maps to confirm where, when and how the work was performed.

Large Clear Display

• Large backlit high visibility LCD screen
• Clear display provides clear, improved and confident location and utility tracing

Custom Frequencies

• Configure for site specific applications
• User configurable modes from 50 Hz to 200 kHz
• Choose from 100 pre-selected frequencies or customise your own frequencies

Compass

• Shows the user the direction of the utility they are locating / tracing

Bluetooth

• Enable wireless communications with software running on a laptop, survey field PC or other GPS enabled device

Increased Transmitter Power Output

• Choose between 5W and 12W transmitter power outputs for superior tracing performance

Selectable Antenna Configuration

• Configure antenna to best optimise for your job site
• Select between more range, sharper response, noise cancelling or easier sweeping

Built For The Most Demanding Environments

• IP65 protection
• Fulfils toughest standards – shock resistant, protected against water and dust ingress

Direction Enabled

• Identifying your target utility amongst multiple parallel utilities
• Apply a special direction enabled signal from the transmitter, the receiver will display an arrow on the compass heading to guide you along the designated utility path

Ambient Interference Measurement (AIM)
When working in congested environments, external interferences can affect the effectiveness of utility tracing. To guard against interference, the Leica ULTRA incorporates advanced Ambient Interference Measurement (AIM), which analyses the surrounding area for noise and recommends the best frequencies for accurate utility tracing.

Offset Measuring
There will always be an occasion when the utility runs close to, or underneath an obstruction. With Offset Measuring, the Leica ULTRA can locate the target line if not directly accessible from above. The function uses the available data to estimate the horizontal and vertical (depth) distance.

Transmitter to receiver link
Advanced communication link between the Leica ULTRA receiver and transmitter, enables you to control the transmitter directly from the receiver. Work smarter and at greater distances to help achieve best practice whilst reducing time spent walking to the transmitter.

Configure for challenging environments
The ULTRA locator can be configured for different project environments. Program modes can adapt the antennas to deliver improved accuracy and repeatability. With over 100 programmable operating frequencies available, the operator can optimise the instrument to overcome the most challenging and complex site conditions.

Ambient Interference Measurements (AIM)
When working in congested environments, the Leica ULTRA incorporates Ambient Interference Measurement (AIM), which digitally analyses the surrounding area for noise and recommends the best frequencies for accurate utility tracing.

Trace utility under an obstruction
There will always be an occasion when the utility runs close too, or underneath an obstruction. With Offset Measuring, the Leica ULTRA can locate the target line if not directly accessible from above. The function uses the available data to estimate the horizontal and vertical (depth) distance.

Clear operational display
The Leica ULTRA integrates a clear graphical LCD screen, with auto-pinpointing directional arrows. The large backlit display ensures confident and fast tracing in all operating conditions, day or night.

Integrate GNSS & GIS systems
Integration with GNSS or GIS data capture devices, Leica ULTRA can deliver a true one man, single step data capture solution for buried utility mapping or surveying applications.

The Leica ULTRA enables operators to achieve ‘best in class’ locating and tracing expectations.

There are two versions of the locators, the Standard version and the Advanced version.

Key Features of Leica DS2000 Utility Detection Radar

• Large and high quality toughpad → Convenient on-site mapping with large display of Panasonic Tablet
• Best ergonomics → height adjustable rig for easy guiding of sensor
• Rugged wheels → fit for any soil condition – providing high detection performance (low noise)
• Foldable system → easy and compact transportation of system
• Dual frequency antenna/sensor → for shallow and deep detection in one system

Leica DS2000 Dual Frequency Antenna
