• Everything readily available for interior finishing
• Increased productivity and precise results
• Perfect for easy stake-out tasks
• Easy to carry due to the robust, attractive, and functional carrying case

	Leica DISTO™ D210 The compact and handy entry-level model has many interesting functions and is still simple to use. Addition and subtraction, area and volume calculations for rapid and reliable site measurement. The last 10 results are stored. Leica DISTO™ D210 – leave the measuring tape behind. Power Range Technology™ IP54 dust and water splash protection Illuminated 3-line display Automatic multifunctional end-piece Read more..
	Leica Lino L2 The time consuming and tedious drawing of lines on the wall is a thing of the past. The Leica Lino L2 projects exactly, quickly and easily – allowing you to concentrate on the job in hand. Pulse function with power-saving mode Modern, ergonomic housing Exact 90° angle Large glass lens Very easy to use Read more..
	Leica TRI-70 small & handy tripod for every day use Small and handy tripod for every day use Aluminium tripod with easy fine adjustment Bubble level ¼” screw on a stable and turnable head plate Transportation length: 0.45m Weight: 1.4kg Working height from 0.40m to 1.15m (including screw-out central pillar) Read more..
	Robust, attractive and functional carrying case.

Leica Disto & Lino Package Contents:

• Leica DISTO™ D210 laser distance meter
• Holster
• Hand loop
• Batteries
• Leica Lino L2 cross line laser
• Magnetic multifunction adapter
• Target plate
• Ball adapter for tripod
• Batteries
• Carrying pouch
• Leica TRI 70 tripod
• Robust Carrying Case



[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”][vc_tab title=”Description” tab_id=”description”]

This laser is multipurpose, making it ideal for tradesmen who work a variety of jobs involving squaring, plumbing, and leveling where a multifunction tool is required. If you are an electrician, plumber, kitchen installer, framer, drywaller, or general contractor, this is the laser for you. It can be used for a variety of applications, including transferring points to the ceiling or lighting installations using plumb points or square a room for partition or walls.

Multi-Use Combination Laser

The GCL 25 laser by Bosch has five different points that offer solutions across the most common applications. The applications it is built to examine include: horizontal leveling, vertical leveling, squaring, plumb transfer, and layout. The best part about this tool’s versatility across common applications is that you no longer have to pack two lasers to the jobsite or off-site project, because you have the combined power of two-in-one. This laser saves you time, money, and space with the simple switch of a button.

User Features

The Bosch GCL 25 laser incorporates several special features to increase both the performance and user ease of the tool. Located conveniently on the exterior of the tool is the on/off sliding button, LED battery status, and line/point selection keypad. The on/off sliding button features a pendulum lock function and is easy to reach. It has three different levels that are: the laser is on and in self-leveling mode, the laser is on but self-leveling is off, or the laser is off. The LED battery status is located on top of the tool for added user convenience so that you don’t have to go looking for the current battery status. In addition, this laser is ergonomically designed for a comfortable and solid grip. On the interior of the tool are the tripod thread, self-leveler, and accuracy feature. The tripod thread measures at 1/4-inch and 5/8-inch. The self-leveling feature measures within 4-degrees. The accuracy feature allows for accuracy within 1/8-inch on horizontal points, 9/16-inches on vertical points, and 1/8-inch on cross-line. The points are also visible for up to 100-feet, and the lines respectively up to 33-feet. This laser is also protected against dust and splash water with ingress protection 54 (IP 54).

Keyboard Operation

The keypad is controlled by how many times you press the keypad. When the pendulum is unlocked and the laser has self-leveling on, the different levels are: default mode where you will have cross-lines (turning it on), 5 point mode (first press of keypad), horizontal line only (second press of keypad), vertical line only (third press of keypad), and return to default mode (fourth press of keypad). When the pendulum is locked (slope mode) and the laser has self-leveling off, the different levels are: cross-line mode (default mode), horizontal line (first press of keypad), vertical line (second press of keypad), or back to default (third press of keypad). Please note that when you are in slope mode, the points are used to plumb and align partitions based on their 90-degree angle to each other. The important precondition for these applications is to have the points leveled. Using the points in non-self-leveling mode may lead to an error. To avoid this error, only the lines are activated for the leveling applications when the laser is in slop mode.

Industry Leader

This GCL 25 laser is outstanding in comparison to the GPL2, GPL3, or CPL5. To begin, it out numbers the other models by featuring a cross-line in addition to five laser dots. It also has a plumb range of 15-feet, a horizontal point range of 100-feet, and a lines range of 30-feet. The accuracy is unique to the GCL25 of within 1/8-inch at 30-feet. The self-leveling within 4-degrees is also only a feature you will get with this laser. It is also not limited to basic applications, covering plumbing, horizontal leveling, squaring, and versatile alignment. It also has the ability to set right angles.

Bosch GCL 25 Five-Point Laser with Cross-Line Features:

• Extremely versatile: cross line laser and five-point laser in one covers all interior alignment applications
• Horizontal and vertical levelling, square, layout and plumb transfer
• Easy to operate using intuitive user interface
• Compact and ergonomic design for maximum grip and end user comfort
• Robust instrument for jobsite use with IP54 dust and splash protection
• 10 m cross line range, 30 m point projection
• Touchpad for line/point selection
• LED light showing battery status
• Tripod compatible 1/4″ and 5/8″ tripod thread
• On/off sliding button with pendulum lock function

Bosch GCL 25 Professional Applications

• Plumbing: Plumb point for pipe installation
• Dry walling: Setting up partition walls
• Electrician: Plumb points for spot lighting
• Kitchen installer: Levelling cupboards

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]

Technical data: Bosch GSL 2 Professional Surface Laser

Specifications	GCL 25 Professional
Working range of laser points	30 m for forward, right and left points   10 m for upward plumb point   5 m for downward plumb point
Working range of laser lines	10 m
Leveling accuracy	0.3 mm / m, plumb points 0.5 mm / m
Self-leveling range	± 4 °
Typical leveling time	<4 s
Dust and splash protection	IP54
Energy supply / Operating time	4 x AA LR06 1.5 V / approx. 15 h   (2 lines + 5 points)
Dimensions (L x H x W)	155 x 118 x 56 mm
Weight including batteries	600 g

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• GCL 25 Professional
• L-Boxx inlay
• 4 x AA Batteries

[/vc_tab][vc_tab title=”Downloads” tab_id=”downloads”]

Brochure

• Bosch GCL 25 Professional Leaflet

User Manual

• Bosch GSL 2 Surface Laser User Manual

[/vc_tab][/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

Laying floor and wall tiles
The Bosch Wall and Floor Tile Laser Level GTL 3 is an ideal tool for laying all floor and wall tiles. The Bosch GTL3 as the name suggests is the only tile laser level on the market to project a third line in the 45⁰ direction in addition to the two standard right-angled lasers. This makes not only parallel laying but also diagonal laying of the tiles very easy and quick. The Bosch GTL 3 Professional Tile Laser can also be used for many other jobs such as wallpapering, boarding, and when laying stones

Clearly visible lasers
The lasers on the Bosch GTL3 new tile laser level are clearly visible thanks to the new strong focusing optical components designed by Bosch. The range when used with the target plate includined is upto 20 meters. The laser line accuracy of 0.2 millimeters per meter makes the Bosch GTL 3 the best tile laser in its class.

Designed for the job
More convenient working is ensured by the lightweight and compact design, and the single-button operation. Two magnetic feet make it easier to fit the tool on a wall or floor using the metal plate that is supplied as standard. The tool is robust and also dust and splash-protected to IP 54. It remains fully functional after being dropped from a height of one meter.

Advantages: Bosch GTL 3 Professional

• With its 45 degree line, laying tiles has never been this fast or easy
• Simple to use with its one button and LED battery indicator
• Projects three laser lines for easy parallel and diagonal laying
• Range of 20 meters with target plate – line accuracy of 0.2 millimeters per metre
• Lightweight and compact design, and single-button operation

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”] Technical data: Bosch GLL 3-80P Professional

Working Range	With target plate 20m
Accuracy	± 0,2 mm/m, ± 0,4 mm/m between 45° and 90°- line
Laser Class	2
Laser Type	635nm, < 1mW
Protection Class	IP54
Batteries	4 x 1.5 V LR6 (AA)
Operating Time	With 2 lines/ 3 lines 18 hrs/12 hrs
Dimension	156 × 102 × 98 mm
Weight	500g
Package	GTL-3, Red Target Plate, Metal plate for use with the magnetic base, Protective carry case, 4 Batteries.

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• Bosch GTL 3 Professional
• Protective Case
• Target Plate
• Metal plate for use with the magnetic base
• 4 batteries

[/vc_tab] [/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”][vc_tab title=”Description” tab_id=”description”]

The working range of the tool has a diameter of about 80 meters with the Bosch LR 2 Professional Receiver. The receiver indicates both with light emitting diodes and also acoustically when the laser beam makes contact with it. There are two accuracy levels: leveling accurate to within three millimeters is done in seconds. If higher precision is required, the receiver does not respond until the result is accurate to within one millimeter.

The robust housing makes the multi line laser insensitive to dust and splash water (protection class IP54). Thanks to its pendulum lock, the Bosch GLL 3-80 P Professional is also perfectly protected against impact when it is transported to the construction site. It remains fully functional when dropped from a height of one meter.

The tool’s “Out-of-Level” function helps to achieve error-free working. If there is an unintentional incline of more than 4°, the Bosch GLL 3-80 P Professional warns the user by means of an acoustic signal and a quickly flashing laser line. The user can fix the pendulum lock if inclined lines are required. Then he can use the tool to project laser lines at any desired inclination.

Multi-line laser
The 3 simultaneously available laser lines ( 1 horizontal and 2 vertical 360° ) enable parallel work in a team with only one tool. Thanks to the very clearly visible laser lines, there is no need to repeatedly position the tool during leveling work in larger rooms. Moreover, the all-round availability of the three laser lines enables simultaneous work in a team with only one tool.

Self-levelling
The Bosch GLL 3-80 P Professional levels itself in less than four seconds. It is very accurate with a leveling accuracy of 0.2 millimeters per meter. There is a 5/8″ and a 1/4″ thread for working with a tripod. In addition to this, the magnetic base plate makes it easy to fix the tool on iron girders or rails. 4° in 4 sec, very precise (± 0.2 mm/m) and range of up to 80 m with receiver.

Highly compact
Compact, easy-to-handle and extremely robust (IP 54). Saves you having to purchase several different tools, the individually switchable lines for the specific applications collectively cover the functions of a cross line laser and a point laser with only one tool. This tool even performs the indoor applications of a rotation laser.

Advantages: Bosch GLL 3-80P Professional

• Provides Three Precise 360-degree Full Plane Coverage in Both Horizontal and Vertical Operations
• IP54 waterproof protection
• Freestanding base with magnets – To attach to metal track. Both 1/4 inch and 5/8th inch tripod mounting
• Simple to use single button operation with little training requirements
• “Pulse” Laser Receiver Mode – Mode for use with laser receiver at long distances and/or in bright light conditions
• 90° horizontal and vertical bright red laser layout lines and electronic self-leveling
• Smart Pendulum Leveling System – Self-levels and indicates out-of level condition. Secure transport lock protects pendulum when unit is switched off

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”] Technical data: Bosch GLL 3-80P Professional

Accuracy	Up to ±1/4-in @ 100-ft
Laser Diode	Class II 630 – 670 nm
Leveling Type	Self-Leveling, Up to 4°
Mount Threading	1/4-20, 5/8-11
Operating Temperature	14° F / -10° C up to 104° F / 40° C
Range	Up to 65-ft (Indoors)
Weight (lbs.)	1.7

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• Bosch GLL 3-80P Professional
• Protective Case
• Target Plate
• 4 x 1.5 V batteries

[/vc_tab] [/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

The Line Laser Level GLL 2-80 P 360 degree dual plane laser for the professional is the world’s first laser tool of its kind to simultaneously project clear horizontal and vertical laser light planes. Therefore, this new Bosch line laser level also performs the functions of a cross line laser level. Bosch have developed the GLL 2-80 as a compact robust unit that is easy to operate, it is the ideal tool for interior fitters and tilers. It levels itself in less than four seconds. It has a leveling accuracy of 0.2 millimeters per meter. There is a 5/8″ and a 1/4″ thread for working with any type of tripod.

The Bosch GLL 2-80P laser clicks easily onto rails thanks to its two magnetic stops. Depending on the work you wants to do, the user can operate the mode switch to select whether he wants to work with only a horizontal or vertical laser line or with both laser lines together.

Two laser diodes provide clearly visible lines. The range of the tool with the Receiver LR 2 Professional has a diameter of approximately 80 meters. The receiver indicates with diodes on the display and also acoustically when the laser beam makes contact with it. Another practical feature are its two accuracy levels: leveling accurate to within three millimeters is performed in seconds. If higher accuracy is required, the receiver does not respond until the result is accurate to within one millimeter.

The “Out-of-Level” function helps to achieve accurate results. The GLL 2-80 P Professional beeps and the laser line flashes quickly to indicate unintentional inclinations of more than 4⁰. The user can fix the pendulum lock if inclined lines are required. Then he can project laser lines at any desired inclination.

The particularly robust housing makes the line laser level insensitive to dust and splash water. Thanks to its pendulum lock, the GLL 2-80 P Professional is also perfectly protected against impact when it is transported to the construction site. It remains fully functional when dropped from a height of one meter.

Advantages: Bosch GLL 2-80P Professional

• Provides precise 360-degree full plane coverage in both horizontal and vertical operations – No rotation or motors to wear out or waste battery power
• Two 360 Degree Laser Planes – That operate together or separately for maximum convenience
• IP54 waterproof protection
• Freestanding base with magnets – To attach to metal track. Both 1/4 inch and 5/8th inch tripod mounting
• Simple to use single button operation with little training requirements
• “Pulse” Laser Receiver Mode – Mode for use with laser receiver at long distances and/or in bright light conditions
• 90° horizontal and vertical bright red laser layout lines and electronic self-leveling
• Smart Pendulum Leveling System – Self-levels and indicates out-of level condition. Secure transport lock protects pendulum when unit is switched off

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”] Technical data: Bosch GLL 2-80P Professional

Accuracy	Up to ±1/4-in @ 100-ft
Laser Diode	Class II 635 – 650 nm
Leveling Type	Self-Leveling, Up to 4°
Mount Threading	1/4-20, 5/8-11
Operating Temperature	14° F / -10° C up to 113° F / 45° C
Range	Up to 65-ft
Weight (oz.)	20.8 oz.

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• Bosch GLL 2-80P Professional
• Protective Case
• Target Plate
• 4 x 1.5 V batteries

[/vc_tab] [/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

The optional LR2 receiver indicates with diodes on the display and also acoustically when the laser beam makes contact with it. A practical feature are its two accuracy levels. Leveling accurate to within three millimeters is done in seconds. If higher accuracy is required, the receiver does not respond until the result is accurate to within one millimeter.

Accurate work is guaranteed by the “Out-of-Level” function. The laser line of the Bosch GLL 2-50 Professional flashes quickly to indicate unintentional inclinations of more than 4°. The user can fix the pendulum lock if inclined lines are required. Then he can project laser lines at any desired inclination.

The particularly robust housing makes the line laser level insensitive to dust and splash water. Thanks to its pendulum lock, the Bosch GLL 2-50 Professional is also perfectly protected against impact when it is transported to the construction site. It remains fully functional when dropped from a height of one meter.

Advantages: Bosch GLL 2-50 Professional

Highly compact 2-line laser – for easy transfer of right angles

• Self-levelling horizontal and vertical pendulum line laser for quick alignment of lines
• High visibility of the laser lines with a working range of 20 m (without receiver)
• Extremely precise in use with an accuracy of ±3 mm at a distance of 10 m
• Vertical, horizontal, and cross line modes for precise alignment
• Easy handling due to single-handed operation
• Horizontal and vertical self-levelling up to ±4°
• Working range of 50 m with the Receiver LR 2 Professional (optional)
• Robust design with softgrip covering protects against knocks
• Pendulum lock ensures safe transport

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”] Technical data: Bosch GLL 2-50 Professional

Laser diode	635 nm, < 1 mW
Operating temperature	-20 – 50 °C
Storage temperature	-20 – 70 °C
Laser class	2
Working range	20 m
Working range with receiver	50 m
Working range without receiver	20 m
Self-levelling range	± 4°
Dust and splash protection	IP 54
Tripod thread	1/4″
Weight, approx.	0.45 kg
Length	118 mm
Width	57 mm
Height	89 mm
Projection	2 lines

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• Bosch GLL 2-50 Professional
• Protective Case
• Alignment Disc
• 3 x 1.5 V batteries

[/vc_tab] [/vc_tabs]

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

The Bosch GLL 2X is a quick and precise solution for diverse applications.

Advantages: Bosch GLL 2X Professional

Highly compact 2-line laser – for easy transfer of right angles

• Easy to use
• Wide versatility
• Get the job done faster and in a professional way
• Projection angle: *60°
• Laser type: 635 nm, class 2
• Working range: 5m
• Precision: ±0.5mm/m (ex-works)
• Self-levelling range: ±4°
• 1m drop resistant
• with slope function

[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”] Technical data: Bosch GPL 5 Professional

Tripod Thread	Yes
Range	up to 5m
Levelling Accuracy @ 5m	± 0.5 mm/m
Self-Levelling Range	±4°
Batteries	2AAA × 1.5V
Dimension	65 × 65 × 65 mm
Number of Laser Lines	2
Weight	250g
Laser Beam Direction	Vertical, Horizontal
Laser Class	2
Delivery Package	Bosch GLL 2X, Clamp MM2, Alkaline Batteries (2 x AAA), Carrying Pouch.

[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]

• Bosch GLL 2X Professional
• Protective Case
• Clamp MM2
• 2 x 1.5 V batteries
