Magellan eXplorist Pro 10 Handheld GIS GPS

Magellan eXplorist Pro 10 GIS Data CollectorMagellan eXplorist Pro 10 GIS Data Collector

The Magellan eXplorist Pro 10 keeps your GIS database accurate and up-to-date. With just one system, large amounts of data can be mapped virtually effortlessly in a minimal amount of time. The small, lightweight, yet rugged eXplorist Pro 10 is the simple solution to your biggest GIS mobile application challenges.


With a powerful 533MHz processor, 128MB RAM, and 4GB of onboard storage, the high-performance, handheld Magellan eXplorist Pro 10 provides all the power needed to work with maps and large-data sets away from the office. Its Windows Mobile® v6.5 operating system allows you to choose a software solution designed specifically for your needs. The unit’s built-in Bluetooth wireless technology makes it easy to receive background map data off the Internet using a Bluetooth-enabled cell phone. It also can be connected to other Bluetooth-enabled devices, such as laser rangefinders and barcode scanners, for convenient cable-free solutions.

Supply your mobile workforce with the durable, compact Magellan eXplorist Pro 10 that incorporates functional features such as photo, video and voice note capture and a high-yield GPS receiver with 3 to 5 meters real-time positioning accuracy (1 to 3 meter post-processed accuracy). The handheld eXplorist Pro 10 is the affordable way to maximize mobile GIS productivity.

  • Windows Mobile 6.5 in English, Spanish, French, Danish, Italian, German, Dutch, Brazilian Portuguese, Russian, Simplified Chinese, Japanese, Korean
  • Samsung 533MHz S3C2450 processor
  • Integrated Bluetooth v2.0 wireless technology
  • Integrated digital camera (color, 3.2 megapixel resolution)
  • 128MB RAM on-board memory
  • 4GB non-volatile internal flash data storage
  • MicroSD (MicroSDHC compatible) memory card slot
  • WQVGA display (400 x 240 Portrait), sunlight-readable transflective color touch screen
  • 16 bit Color support
  • Integrated speaker and microphone
  • 3D compass, Pressure Altimeter and Barometer
  • Powered by two AA batteries, lasting up to 15 hours w/ LCD backlight at 40 Nits
  • Integrated high-sensitivity SIRFstar III GPS receiver and Multidirectional Patch antenna
  • 3 to 5 meter typical accuracy
  • 1 to 3 meter post-processed accuracy
  • NMEA and SiRF protocol support

Technical data: Magellan eXplorist Pro 10 GIS Data Collector

Product Number TP10ENSGXWW
DEVICE
Dimensions (English) 2.57″ x 5.04″ x 1.45″
Dimensions (Metric) 65.3mm x 128mm x 36.8mm
Weight (English) 6.87oz
Weight (Metric) 195g
Battery Type 2xAA
Battery Life 15 Hours
Camera Yes
Microphone Yes
Waterproof IPX-7
Speaker Yes
Stereo Audio Jack Yes
Available User Storage 4GB
CPU 533MHz
Expandable Memory microSD
Temperature Range (F) 14F to 140F
Temperature Range © -10C to 60C
Suspend Mode Yes
SCREEN
Display Resolution, WxH WQVGA, 240 x 400
Screen Size 3.0″
Display Type Color, Transflective
Touch Screen Yes
GPS & SENSORS
GPS Accuracy Up to 3-5 meters (1-3 meter post-processed)
High-Sensitivity GPS SiRFstarIII™
Antenna Type Multidirectional Patch
3-Axis Electronic Compass Yes
WAAS/EGNOS/MSAS Yes
MAPPING & NAVIGATION
Coordinates Systems & Datums Yes
USER GENERATED CONTENT
Accepts GPX Files Yes
Picture Viewer Yes
INTERFACE & COMMUNICATIONS
Communication Protocol USB Mass Storage
USB PortYes Yes
NMEA Output Yes
PC Compatible Yes
Bluetooth Yes

About Magellan

Magellan is a leading portable GPS navigation consumer electronics company. Founded in 1986 and with over 200 key patents in GPS technology, Magellan is recognized as an industry innovator and leader. Magellan is the creator of the award-winning Magellan RoadMate®, and Maestro™ series portable car navigation products, as well as the Magellan Triton® and eXplorist® outdoor handheld navigation devices. Magellan is also proud to offer innovative Mobile GPS solutions including the RoadMate App for iPhone and Premium Car Kit accessory.
