Leica LDT-05 Digital Theodolite

The Leica LDT-05 digital electronic theodolite is designed for enhanced performance in construction applications. Work faster with the advanced features of the Leica Digital Theodolite LDT-05 to improve productivity while increasing the bottom line.

Fast set-up and easy to use The advanced features of the LDT-05 Leica Theodolite makes set-up fast and very easy. The intuitive on-board functions allow most anyone to use this great tool, even those with minimal experience! Economical and affordable The LDT-05 is attractively priced to fit everyone’s budget. Contact us today for more details and a formal quote.

  • 5-second accuracy – High accuracy for tight tolerances
  • Automatic vertical compensation – A tilt warning occurs if out of compensation range, preventing costly errors
  • Optical plummet – a Makes setting over a point a snap — much faster & easier
  • Precision dual LCD panels with large, easy-to-read numbers
  • Zero resetting – Instantly resets the horizontal angle to zero
  • The Leica LDT-05 includes both rechargeable and alkaline battery options

Contact Us for Best Price

Get Quotation

Leica Electronic Theodolite LDT05 Key Features:

Leica theodolite is a new generation technical equipment for measuring both horizontal and vertical angles, It is a key instrument for land surveying and civil engineering work. The electronic theodolite consists of a telescope movable within two perpendicular axes – the horizontal axis, and the vertical axis. When the telescope is pointed at a desired object, the angle of each of these axes can be measured very precisely.

Enhanced Reliability

  • 5’’ horizontal and vertical readout
  • Precision dual LCD panels with large, easy-to-read numbers
  • Vertical angle measuring provides three different options plus percentage of grade

Easy-to-read & easy-to-use

  • Auto Power Off option
  • Optical plummet
  • Zero resetting
  • Removable tribrach for multiple set-ups

Audible right-angle notification

  • Once the (0) horizontal angle is determined, the Leica LDT-05 emits an audible tone for each of the right angle directions
  • Beeping stops when the units comes within +/– 1°

Rugged IP54 protection

  • Water resistant, sealed construction
  • One year warranty

Leica Digital Theodolite LDT 05 Technical Specifications:

Model Leica LDT-05
Precision 5”
Display resolution 1” or 5”
Display units DEG (360° 00’ 00”), GON (400), MIL (6400), V / %
Telescope
Magnification 30x
Objective aperture 45 mm (1.7 in)
Minimum focusing distance 1.35 m (4.43 ft)
Stadia multiplication factor/constant 100/0
Compensator
System Automatic vertical compensator, User set On/Off
Working Range ± 3’
Operation
Display Double side large character back-lit LCD
Keys 6 one touch button functions
Optical plummet
Image Erect
Magnification 3x
Field of view
Focusing range 0.5m~
Environmental conditions
Protection to dust and water dust and water resistant
Weight
Weight including battery and tribrach 4.6 kg (9.9 lb)
Battery/Power management
Type of battery Rechargeable NiMH, replacement alkaline battery pack
Operation period without laser plummet 36 h
Get Quote Now

Leica LDT-05 Digital Theodolite

The Leica LDT-05 digital electronic theodolite is designed for enhanced reliability in construction applications.
