Bosch GSL 2 Surface Levelling Laser

Bosch GSL2 Manual Surface Laser in L-Boxx

The Bosch GSL 2 surface laser is the world’s first surface laser. It allows for quick scanning of the entire floor, increased accuracy. This laser is ideal for users who are seeking a more efficient, convenient, and accurate tool for daily use as well as those looking for more than just a spot check. Diverse enough for current laser users, this tool is also ideal for flooring estimators, screed workers, tilers, and many more. It is not intended for checking the slope of a floor or wall flatness.

Buy Online →

[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”]

Be honest. Do you check floor surfaces completely and accurately every time? This was almost impossible anyway with the previous point-by-point methods. Or if at all possible, it would require a lot of time and personnel. This is now visibly easier to do because the new GSL 2 Professional enables you to check floors completely in no time. It is ideal for everyone who works with floor surfaces – for composite floor layers, tilers, parquet layers, drywallers and surveyors.

The principle is ingeniously simple – and simply ingenious. The floor surface laser projects two lines onto the floor. If the surface is flat, the lines will be exactly on top of each other. The user will see them as only one line. Where the lines are apart, the floor is not flat.

Fast and Easy

No need to bend down, re-measure, or get someone to assist you: even large surfaces can be comfortably checked by only one person with a remote control!


The GSL 2 enables to see the high and low spots at a glance with accuracy and reliability

Complete coverage

Unlike conventional spot checking methods the GSL 2 checks floor surface in a radius of up to 60 ft in just a few minutes. It saves time and increases the accuracy

Bosch GSL 2 Professional Surface Laser Features:

  • Speed – check large areas quickly and efficiently
  • Precision – surface laser allows user to measure irregularities height / depth to millimetre accuracy
  • Complete coverage – checks surfaces completely oppose to conventional spot checking methods
  • Visibility – laser lines clearly visible on surface up to 10 m and 20 m with target plate
  • Robust – comes with IP54 dust and splash protection
  • Innovation – new innovative method of checking surface evenness aimed at saving the user time and money
  • Carry handle – allows for easy transportation
  • Height adjustment – manually adjust height of unit
  • Manual rotary base – rotate base to face required direction
  • Uses standard Bosch 10.8v li-ion batteries (not supplied) or 4 x AA batteries
  • Battery status LED shows battery life
[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]

Technical data: Bosch GSL 2 Professional Surface Laser

Accuracy Up to ±1/8-in @ 30-ft (Horizontal & Vertical)
Battery 12V Max Lithium-ion Battery
Battery 4 AA 1.5V Batteries
Dimensions 8.3″ x 7.7″ x 8.1″
Laser Diode 630 – 670 nm Class 3R
Leveling Type Self-Leveling, Up to 4°
Operating Temperature 14°F / -10°C ~122°F / 50°C
Range Up to 30ft without Target Plate, Up to 60ft with Target Plate
Weight (lbs.) 3.3 lbs
[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”In The Box” tab_id=”inthebox”]
  • GSL 2 Professional (without motor)
  • 4 x AA 1.5 V batteries
  • Target
  • Laser viewing glasses
  • L-BOXX carrying case
[/vc_tab][vc_tab title=”Downloads” tab_id=”downloads”]


User Manual

[/vc_tab] [/vc_tabs]
