Leica Jogger 28 Automatic Level

You are here: Home » Auto Level » Leica Jogger 28 Automatic Level

Leica Automatic Level Jogger 24

Leica Jogger 28-Fit for Work

Leica’s most economical Automatic Builders Level  is designed specifically for general construction applications. The Leica Jogger 28 has a 28x magnification and is the ideal instrument for all your daily leveling tasks such as Building and Civil Engineering, Profiling, Landscaping, and Area Leveling.

Automatic optical levels are also known as site levels or dumpy levels.


[vc_tabs interval=”0″ width=”1/1″ el_position=”first last”] [vc_tab title=”Description” tab_id=”description”] Fit for Work – Great features and great performance:

  • Magnification: 28x
  • Automatic, air-damped compensator
  • Smooth, double-sided endless fine drive for easy and precise targeting
  • Horizontal circle with 360° division

Fit for Work – Quality and Endurance:

  • Water resistant (IP54) for instrument use under harsh environmental conditions.
  • 1 year warranty.

Fit for Work – Great Jogger package

Tripod and staff are important parts of any levelling equipment. Get better results with Best Quality Tripods and Staffs.

Applications

  • Levelling footing
  • Concrete pours
  • Elevation control
  • Grade checking
  • Excavations
  • Drainage pipes
  • Walkway construction
  • Profiling
  • Area levelling
[/vc_tab][vc_tab title=”Specifications” tab_id=”specifications”]
Leica Jogger Technical data Leica Jogger 20 Leica Jogger 24 Leica Jogger 28 Leica Jogger 32
Standard deviation per 1 km double-run level 2.5 mm 2.0 mm 2.0 mm 2.0 mm
Magnification 20x 24x 28x 32x
Shortest focusing distance 1 m 1 m 1 m 1 m
Compensator
Working range
Setting range
±15′
0.5″
±15′
0.5″
±15′
0.5″
±15′
0.5″
Operating temperature -20°C to +40°C -20°C to +40°C -20°C to +40°C -20°C to +40°C
Weight (net) 1.5 kg 1.5 kg 1.5 kg 1.5 kg

Leica Jogger 28 Package:

  • 1 No. Leica Jogger 28 Automatic Optical Level
  • 1 No. Hard ABS Protective Case
  • 1 No. Adjustment Screwdriver
  • 1 No. Adjustment Allen Key
  • 1 No. Instruction Manual
  • 1 No. 12 Month Warranty
  • 1 No. Aluminium Tripod
  • 1 No. Aluminium 5m Levelling Staff
[/vc_tab][vc_tab title=”Gallery” tab_id=”gallery”] [/vc_tab][vc_tab title=”Downloads” tab_id=”downloads”] Leica Jogger 28 Catlogue[/vc_tab] [/vc_tabs]
[vc_separator width=”1/1″ el_position=”first last”]

About Leica Geosystems – when it has to be right

With close to 200 years of experience pioneering solutions to measure the world, Leica Geosystems products and services are trusted by professionals worldwide to help them capture, analyze, and present spatial information. Leica Geosystems is best known for its broad array of products that capture accurately, model quickly, analyze easily, and visualize and present spatial information.

Those who use Leica Geosystems products every day trust them for their dependability, the value they deliver, and the superior customer support. Based in Heerbrugg, Switzerland, Leica Geosystems is a global company with tens of thousands of customers supported by more than 3,500 employees in 28 countries and hundreds of partners located in more than 120 countries around the world. Leica Geosystems is part of the Hexagon Group,
